Option & Equipment
Audio system feature, 2 speakers
Audio System, AM/FM stereo with CD player, auxiliary jack, USB port and Bluetooth® (STD)
Wheels, 16" x 6, K. steel (STD)
Windshield wiper, pulse, wet arm
Grille, Silver
Tires, front, 215/85R16 E, LRR (low rolling resistance) tubeless steel belted radial, all-season
Tires, rear, 215/85R16 E, LRR (low rolling resistance) tubeless steel belted radial, all-season
LED Headlamps
Assist steps
Glass, tinted
PIO, Mirror, outside left-hand and right-hand with integral convex mirrors, heated (Port Installed Option)
Arc White
PIO, Roof-air deflector (Port Installed Option)
Seat, front high back bucket driver and passenger tricot cloth covered reclining high back driver seat with single two-occupant fold down passenger seat (STD)
Lighting, interior dome
Windshield washer bottle access on passenger side dash when passenger-side door is open
Air conditioning, single-zone manual, integral in-dash mounted
Steering column, Tilt-Wheel
Steering wheel, urethane
Floor mats
Windows, power
Cup holders
Cruise control, electronic, automatic
Seat trim, Cloth
Storage, door pockets
Storage, seatback pockets
Driver Information Center
Door locks, power
Medium Ash Gray, Cloth seat trim
PIO, Rear dome and body lamp switch (Port Installed Option)
PIO, Back-up alarm (Port Installed Option)
PIO, Remote Keyless Entry (Port Installed Option)
Vehicle Application Truck
Emissions, 50 state certification
Incomplete vehicle certification
Rear axle, 4.10 ratio
Drivetrain, rear-wheel drive
Exhaust, single outlet
Frame, ladder-type channel frame. Full C section straight frame 33.5" (85.1 cm) wide. Yield strength 44,000 psi, section modulus 7.20 cu.in. and RBM 316,800 lb-ft/in per rail.
Rear suspension, 12,900 lbs. (5851 kg), multi-leaf, semi-elliptical steel alloy. Includes shock absorbers
Battery, 750 cold-cranking amps, 12-volt single, maintenance free, frame-mounted battery box
Air cleaner, heavy-duty, 11" diameter dry paper single element. Air cleaner canister standard with air restriction gauge. Back of cab location.
Fuel tank, 38.6 Gallon, (146L), rectangular fuel tank mounted between frame rail with electric type fuel pump (mounted in tank). Through the rail fuel fill.
GVWR, 12,000 lbs. (5443 kg)
Brakes, 4-wheel antilock, front and rear disc
Front axle, 6,830 lbs. (3098 kg), reverse Elliot "I"-beam includes integral hydraulic power steering, with an 18.8-20.9:1 gear ratio
Wheelbase, 132.5" (336.6 cm)
Axle, limited slip
Preferred Equipment Group includes standard equipment
Ship Thru, Produced and shipped to Morgan Corporation - Lakeland, FL The FINAL DESTINATION for trucks shipped here MUST BE LOCATED IN THE JACKSONVILLE, FL PORT DELIVERY AREA. Trucks requiring delivery outside of the Jacksonville port service area may incur additional transportation charges.
Ship Thru, Ocean Freight Surcharge
Daytime Running Lamps
