Option & Equipment
GVWR 16500 lbs. (7484 kg) capacity - GCWR limited to 24000 lb. (10866 kg) NOTE: Trucks that are used primarily to tow a trailer may be liable to Federal Excise Tax (FET) - check with IRS for guidelines
Air cleaner dry type
Cooling anti-freeze protection temperature - -40 degrees F (-40 degrees C)
Road speed governor controlled by the speed rating of the tires ordered which will be less than or equal to 85 mph (137 kph)
Alternator AD244 Delco-Remy 150-amp maximum (N/A with YW2 wrecker package)
Front axle 7000 lbs. (3175 kg) capacity - I-beam Wide-trac. Up to 53 degree turn angle (Includes 4-piston brake apply calipers)
Front suspension tapered leaf 7000 lbs. (3175 kg) capacity (includes stabilizer)
Front shock absorber diameter 1.375" (35mm)
Front stabilizer bar 2" x 2" square tube (5 cm x 5 cm)
Front wheels 19.5" x 6.75" (49.5 cm x 17.1 cm) steel disc - 8-hole. 10000 lbs. (4536 kg) capacity (Requires Q83 steel rear wheel)
Front tire size 225/70R19.5F - 7280 lbs. (3802 kg) capacity (With R4A Goodyear or R4L Michelin requires R3C front premium highway tread; with R4N Bridgestone requires R3M front all season tread)
Front tire manufacturer code Goodyear (Requires S4A Goodyear)
Front tread premium highway (Requires R4A Goodyear or R4L Michelin)
Rear axle single speed 11000 lbs. (4990 kg) capacity - full floating Includes 2-piston brake applied calipers
Rear wheel drive
Rear suspension tapered leaf 11000 lbs. (4990 kg) capacity (Requires GN1 rear stabilizer bar and GL4 rear axle)
Rear shock absorber - included with tapered leaf and optional with multi-leaf suspensions. (Included with GR2 or GXA rear tapered leaf suspensions)
Rear stabilizer bar provides increased load stabilization - improves handling and reduces vehicle roll. Does not adversely affect ride. Diameter 44mm (Required with taper leaf springs) (Available with multi leaf springs)
Rear wheels 19.5" x 6.75" (49.5 cm x 17.1 cm) steel disc - 8-hole 20000 lbs. (9072 kg) capacity (Requires Q82 steel front wheel)
Rear tire size 225/70R19.5F - 13660 lbs. (6196 kg) capacity (With S4A Goodyear requires S3C rear premium highway tread or S3H rear traction tread; with S4L Michelin requires S3C rear premium highway tread or S3J rear highway traction tread; with S4N Bridgestone requires S3M rear all season tread)
Rear tire manufacturer code Goodyear (Requires R4A Goodyear)
Rear tread premium highway (Requires S4A Goodyear or S4L Michelin)
Wheelbase 169" (429.3 cm) - with 60" (152.4) CA and 121" (307.3 cm) CE. Includes a 8 mm 80000 psi (551600 kPa) yield strength steel frame RBM: 824800 section Modulus 10.31
Frame 8mm - 80000 psi (551600 kPa) yield strength steel frame RBM: 610400 Section Modulus 7.63
Fuel tank single 40-gallon (151L) fuel capacity - gas or diesel located behind rear axle with fuel fill neck through frame rail DRIVER SIDE FILL NECK ONLY. NO AUXILIARY FUEL PORTS (N/A with YW2 Wrecker Package) MINIMUM OVERHANG = 60" (5 FEET)
Fuel sender assembly. Robust fuel pump
Tethered fuel cap
Brakes front power 4-wheel disc 4 channel ABS 4-piston - (See Front Axle options for more detail)
Brakes rear power 4-wheel disc 4 channel ABS 2-piston - (See Rear Axle options for more detail)
Bumper front steel 96" (243.8 cm) wide - styled to minimized wall to wall turn diameter painted argent
Windows Solar-Ray tinted - front windows only; excluding rearside and rear windows
Exterior roof drip moldings
Provisions for mounting front license plate
Integral grille and fenders - The grille is the same color as hood with single halogen headlamps.
Windshield wipers 2-speed and intermittent with pulse washers
Daytime running lamps
Steps under cab doors
Mirror manual 102" (259 cm) wide load integral arm integral convex mirror - black molded composite 12" x 7" (30.5 cm x 17.8 cm) with 6" x 7" (15.2 cm x 17.8 cm) convex section
Paint scheme solid upper color Summit White
Paint scheme solid lower color Summit White
Molded vinyl floor covering
Vinyl door trim panels - with storage pocket on front doors beverage holders and reflector on all doors
Headlamp warning buzzer
Steering wheel simulated leather
Sunshades passenger side and driver side vinyl-covered
Warning tone key-in-ignition
Seat belt warning indicator
Trim console - located next to driver's seat and two cupholder
Coat hooks (2) located on cab back panel
Cloth headliner
Steering power - ZF variable ratio power
Powerpoints - one in-cab power source (in addition to optional cigarette lighter) for electrical plug-in accessories
Underhood bodybuilder connections accessory power supply - Provides 12V power supply from the battery with two separate 30 amp fused circuits
Air conditioning not desired - this option should be ordered only when a customer does not require air conditioning
Seat driver high-back bucket Fixed height manual adjuster - storage in the seat riser with a small lip at the front to stop contents from sliding out
Seat passenger high-back bucket Fixed height manual back angle adjuster - storage in the seat riser with a small lip at the front to stop contents from sliding out
Rear bench seat
Provisions for stereo - Includes AM/FM antenna lead wiring for speakers and separate door chime module (N/A with ZQ2 driver convenience package)
Interior trim Very Dark Pewter (Requires 69V Very Dark Pewter Vinyl or 69C Very Dark Pewter Cloth)
Seat trim vinyl Very Dark Pewter
4-wheel disc 4-channel ABS
Air bags Supplemental Inflatable Restraints not included.
This vehicle does not include any air bags
DURAMAX DIESEL 6600 300 HP (223 KW) @ 3000 RPM 605 LB-FT (820 N-M) TORQUE @ 1600 RPM
(Includes KPJ Engine shutdown) Oil Level Sensor: Warning sensor for low oil levels
