Option & Equipment
4500 HD Series (Included and only available with (C7Y) 14,001 lbs. GVWR, (C5B) 15,000 lbs. GVWR, (C7P) 16,000 lbs. GVWR or (C7R) 16,500 lbs. GVWR.)
Engine, Duramax 6.6L Turbo-Diesel V8, B20-Diesel compatible 350 hp at 2700 rpm, 700 lb-ft torque at 1600 rpm
Rear axle, 4.10 ratio Max road speed: 79 MPH
GVWR, 16,500 lbs. (7484 kg) (Silverado 4500 HD models with (FQT) requires one of the following combinations: (1) (FTC) and (FTW) and (GL4) and (GR3). Requires (G68). (2) (FTC) and (FTW) and (HD2) and (GR4). Requires (G68). (3) (FTC) and (FTW) and (HD1) or (J27) and (GR4). Requires (G68). (4) (FTA) and (FK6) and (FN1) or (GL4) and (GR3). Requires (PCJ). (5) (FTA) and (FK6) and (HD1) or (J27) and one of the following rear suspensions: (GR4) or (FU7). Requires (PCJ). Silverado 4500 HD models without (FQT) requ
Wheelbase, 141" (358.1 cm), 60" CA (Requires (F0C) 49" axle to end of frame, (F0D) 63" axle to end of frame or (F0K) 91" axle to end of frame and (NPR) exhaust. Requires (PCJ) Vocational Specific Heavy Suspension Package, when ordering (FTA) 7,000 lbs. Front axle/(FK6) 7,000 lbs. Front suspension or (FTL) 8,000 lbs. Front axle/(FSN) 8,000 lbs. Front suspension and/or (FU7) 15,500 lbs. rear suspension. Not available with rear air suspensions.)
Front axle, 6,250 lb. (2,835 kg), Dana Spicer D800-N, "I"-beam, non-driving (Requires (FTW) 6,250 lb. front suspension. Includes (G68) rear shock absorbers. Not available with rear air suspensions.)
Front suspension, 6,250 lbs. (2,835 kg) multi-leaf, includes shock absorbers (Not available with rear air suspensions.)
Rear axle, 11,000 lbs. (4,999 kg) Dana Spicer S14-110, single reduction
Rear suspension, 11,000 (4,990 kg) multi-leaf, vari-rate (Not available with air suspension.)
Emissions, USA 50 State certified
Transmission shift control calibration, fuel sense Performance
Rear wheel drive
Batteries, heavy-duty dual 1100 cold-cranking amps includes battery box mounted to left side under cab
Alternator, 150 amps
Incomplete vehicle
Axle to End of Frame, 49" (Requires wheelbase (ED5) 201", (ED9) 165", (ER2) 189" or (FQT) 141". Not available with (G40), (GP1) or (GP8) rear air suspension.)
Axle lubricant, rear, synthetic oil EmGard FE -75W-90
Shock Absorbers, rear (Included with (FTC) 6,250 lb. front axle.)
Steering, power (Bosch S2 8014 Plus)
Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
Fuel tank, rear only, 40 gallon mounted between frame side rails and behind rear axle
Fuel, diesel B20
Capped Fuel Fill
Exhaust system, right side exit, behind rear wheel (Requires (FQT) 141" wheelbase.)
Spare tire delete
Wheel, spare delete
Bumper, front, Black
Front fender extension, mold-in-color Black (Not available with (FNP) Body color front fender extension.)
Grille, base, molded in color, Black
Grille guard screen, insect protection (mounted behind grille)
Headlamps, halogen projector-beam
Lamps, cargo area, cab mounted with switch on center switch bank
Lamps, Smoked Amber roof marker
Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
Mirrors, outside high-visibility vertical camper-style, Black with manual folding and extension and lower convex spotter glass
Glass, solar absorbing, tinted
Antenna, fixed mast
Door handles, Black
SiriusXM, delete
Audio system feature, 4-speaker system
Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
Seat Belt, Black
Floor covering, Graphite-colored rubberized-vinyl
Steering wheel, urethane
Steering column, manual Tilt-Wheel
Instrumentation, 6-gauge cluster featuring speedometer, fuel level, engine temperature, tachometer, voltage and oil pressure
Speedometer, miles/kilometers
Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information
Windows, manual driver and front passenger
Cruise control, steering wheel-mounted
Mirror, inside rearview manual day/night
Visors, driver and front passenger, vinyl
Assist handle, front passenger and driver on A-pillars
Brake, parking, driveline park brake system
Traction control
Daytime Running Lamps, with automatic exterior lamp control
OnStar, delete
Horn, single-note
