Option & Equipment
Audio system feature 4-speaker system
Audio system 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (Requires (AE7) front 40/20/40 split-bench seat. Not available with (UE1) OnStar or (U2K) SiriusXM Radio.) (STD)
SiriusXM delete
Audio system 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (STD)
Glass solar absorbing tinted
Grille guard screen insect protection (mounted behind grille)
Mirrors outside high-visibility vertical camper-style Black with manual folding and extension and lower convex spotter glass
Antenna fixed mast
Spare tire delete (STD)
Wheel spare delete
Door handles Black
Lamps rear stop/turn/backup (1-piece assembly) with license plate light
Grille base molded in color Black
Wheels 19.5" x 6.75" steel Black painted 8-holes hub piloted (STD)
Front fender extension painted body color
Lamps cargo area cab mounted with switch on center switch bank
Assist steps
Lamps Smoked Amber roof marker
Headlamps halogen projector-beam
Bumper front Black
Paint solid
Tires rear 225/70R19.5G highway blackwall Goodyear Max Axle Load: 15000 lb.
Summit White
Paint Scheme Style 1
Tires front 225/70R19.5G highway blackwall Goodyear Max Axle Load: 7940 lb.
Visors driver and front passenger vinyl
Seat trim Vinyl
Speedometer miles/kilometers
Interior trim Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
Cruise control steering wheel-mounted
Door locks power
Windows manual driver and front passenger
Air conditioning single-zone
Assist handle front passenger and driver on A-pillars
Driver Information Center 3.5-inch diagonal monochromatic display provides warning messages and basic vehicle information
Floor covering Graphite-colored rubberized-vinyl
Steering wheel urethane
Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
Steering column manual Tilt-Wheel
Seats front 40/20/40 split-bench 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
Mirror inside rearview manual day/night
Seat Belt Black
Dark Ash seats with Jet Black interior accents Vinyl seat trim
Emissions 50 state certification
Front suspension 6250 lb. (2835 kg) multi-leaf includes shock absorbers (Not available with rear air suspensions.) (STD)
Alternator 150 amps
Brakes hydraulic heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
Axle Open rear axle non-locking rear
Capped Fuel Fill
Front axle 6250 lb. (2835 kg) Dana Spicer D800-N "I"-beam non-driving (Requires (FTW) 6250 lb. front suspension. Includes (G68) rear shock absorbers. Not available with rear air suspensions.)
Steering power (Bosch S2 8014 Plus)
Axle to End of Frame 49" (Requires wheelbase (ED5) 201" (ED9) 165" (ER2) 189" or (FQT) 141". Not available with (G40) (GP1) or (GP8) rear air suspension.)
Fuel tank rear only 40 gallon mounted between frame side rails and behind rear axle
GVWR 16500 lb. (7484 kg) (Silverado 4500 HD 2WD Regular Cab models require one of the following combinations: (1) (FTC) 6.25k front axle and (FTW) 6.25k front suspension and (GL4) 11k rear axle and (GR3) 11k rear suspension. (2) (FTC) 6.25k front axle and (FTW) 6.25k front suspension and one of the following rear axles: (HD2) 13.5k rear axle (HD1) 15k rear axle or (J27) 15.5k rear axle and (GR4) 13.5k rear suspension. (3) (FTA) 7k front axle and (FK6) 7k front suspension and (FN1) 10k rear axle or (GL4) 11k rear axle and (GR3) 11k rear suspension or (G40) 12K Rear air suspension. (4) (FTA) 7k front axle and (FK6) 7k front suspension and (HD1) 15k rear axle or (J27) 15.5k rear axle and one of the following rear suspensions: (GR4) 13.5k rear suspension (FU7) 15.5k rear suspension (GP1) 13.5K rear air suspension (GP8) 15.5k rear air suspension (91B) 13.5k LiquidSpring prep single volume rear suspension (91C) 13.5k LiquidSpring prep stacked volume rear suspension (91D) 15.5k LiquidSpring prep single volume rear suspension or (91E) 15.5k LiquidSpring prep stacked volume rear suspension.) (STD)
Emissions USA 50 State certified
Rear wheel drive
Incomplete vehicle
Fuel diesel B20
Rear axle 11000 lb. (4999 kg) Dana Spicer S14-110 single reduction
Axle lubricant rear synthetic oil EmGard FE -75W-90
Rear axle 4.10 ratio Max road speed: 79 MPH
Rear suspension 11000 lb. (4990 kg) multi-leaf vari-rate (Not available with air suspension.) (STD)
Shock Absorbers rear (Included with (FTC) 6250 lb. front axle.)
Trailering provisions trailering wire harness only trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
Batteries heavy-duty dual 1100 cold-cranking amps includes battery box mounted to left side under cab
Exhaust brake
Trailer brake controller integrated
26000 lb. GCWR (11793 kg)
4500 HD Series
Front suspension 6250 lb. (2835 kg) multi-leaf includes shock absorbers (STD)
Wheelbase 189" (480.1 cm) 108" CA
Shock Absorbers rear
GVWR 16500 lb. (7484 kg) (STD)
Exhaust system rear exit
Rear suspension 11000 lb. (4990 kg) multi-leaf vari-rate (STD)
Front axle 6250 lb. (2835 kg) Dana Spicer D800-N "I"-beam non-driving Includes (G68) rear shock absorbers.
Power Take-Off (PTO) not installed
Work Truck Preferred Equipment Group includes standard equipment
Daytime Running Lamps with automatic exterior lamp control
Horn single-note
Airbags Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Rear Vision Camera display integrated into Radio (Shipped loose in cab for upfitter installation.)
OnStar delete
Airbag deactivation switch frontal passenger-side (Included and only available with (AY0) airbags.)
StabiliTrak Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
Brake parking driveline park brake system
Traction control
REAR AXLE 4.10 RATIO
Max road speed: 79 MPH
WORK TRUCK PREFERRED EQUIPMENT GROUP
includes standard equipment
SPARE TIRE DELETE
(STD)
SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER
driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
GVWR 16500 LB. (7484 KG)
FRONT AXLE 6250 LB. (2835 KG) DANA SPICER D800-N "I"-BEAM NON-DRIVING
Includes (G68) rear shock absorbers.
FRONT SUSPENSION 6250 LB. (2835 KG) MULTI-LEAF INCLUDES SHOCK ABSORBERS
REAR SUSPENSION 11000 LB. (4990 KG) MULTI-LEAF VARI-RATE
AUDIO SYSTEM 4.2" DIAGONAL COLOR DISPLAY
AM/FM stereo with USB port and auxiliary jack (STD)
ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-DIESEL COMPATIBLE
350 hp @ 2700 rpm
700 lb.-ft. torque @ 1600 rpm (STD)
HIGHWAY SERVICE TRANSMISSION AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE ALLISON A1700HS
ratios: 3.10 1ST
1.80 2ND
1.40 3RD
1.00 4TH
0.70 5TH
0.61 6TH Highway Series
WHEELS 19.5" X 6.75" STEEL BLACK PAINTED 8-HOLES HUB PILOTED
TIRES FRONT 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR
Max Axle Load: 7
940 lb.
TIRES REAR 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR
Max Axle Load: 15
000 lb.
Back-Up Camera
Stability Control
